Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane

Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane

MOQ: 1000m²
Price: US$1.58-1.8/Square Meter
Standard Packaging: Tray packaging
Delivery Period: 7-8 work days
Payment Method: T/T
Supply Capacity: 720,000 square meters per year
Detail Information
Place of Origin
China
Brand Name
YU WANG
Certification
ISO
Model Number
ZZ-1.5
Name:
Bitumen Waterproofing Membrane
Model Number:
ZZ-1.5
Trademark:
Yu Wang
Texture Of Material:
Modified Asphalt
Surface:
PE Film, Sand Or Mineral Particles, Aluminum Foil
Impermeability:
0.2Mpa, Impermeable For 120min
Origin:
China
Low Temperature Resistance:
-30°C Without Cracks
Holding Viscosity:
≥20min
Thickness:
1.2mm/1.5mm/2.0mm/3.0mm/4.0mm
Length:
10m;15m;20m
Specifications:
1m*10m/roll
Heat Resistance:
Sliding At 70°C Not Exceeding 2mm
Weight:
31-44kg/roll
Throughput:
720,000 Square Meters Per Year
Transport Packages:
Tray Packaging
Technical Specifications:
40 Kg/piece
Thermal Stability:
Appearance Without Bulging, Wrinkles, Sliding, Or Flowing
Highlight:

Single Sided Bitumen Waterproofing Membrane

,

Single Sided Bituminous Waterproofing Membrane

,

Roof Waterproof Self Adhesive Membrane

Product Description

Single Sided Self-Adhesive Bitumen Waterproofing Membrane Suitable For Roof Waterproofing



Product Overview:
The self-adhesive polymer modified asphalt waterproofing membrane is made of synthetic rubber such as SBS, high-quality road   asphalt, and tackifiers as the base material, with polyester film (PET), polyethylene film (PE), aluminum foil or silicon coated  isolation film as the upper surface material, and silicon coated isolation film as the anti sticking layer on the lower surface. It is a  self-adhesive polymer modified asphalt tire free waterproofing membrane.

Technical Parameters:

Name Self-adhesive polymer modified asphalt waterproofing membrane
Holding viscosity More than 20 minutes
Application area Non exposed roofs, underground waterproofing, water channels, swimming pools, waterproofing works that cannot use open flames, etc
Impermeability 0.3Mpa,120min impermeable
Heat resistance No flow or dripping at 70° C
Low temperature bending property No cracks at﹣30°C
Thickness 1.2mm;1.5mm;2.0mm
Width 1m;2m(Sizes can be customized)
Length 20m(Sizes can be customized)
Specifications 20m*1m/roll
Supply capacity 10000m²/day
Sample Freely Supplied
Period for dispatch 7-8 working days (according to quantity)



Product Description:


Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 0

Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 1Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 2Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 3

Characteristics of self-adhesive polymer modified asphalt waterproofing membrane:
●Cold construction: no use of open flames, no use of adhesives, energy-saving, environmentally friendly, low-carbon, and economical;
●Excellent adhesive performance, long-term in a viscoelastic state, ensuring the integrity of the waterproof layer;
●High elongation performance and excellent shear strain;
●Excellent low-temperature performance;Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 4

Scope of application:

Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 5

●Waterproofing of non exposed roofs and underground works;
●Waterproofing of municipal engineering such as water channels and swimming pools;
●Waterproofing of subway engineering using open cut method;
●Especially suitable for waterproofing projects that cannot use open flames;
●Excellent low-temperature performance is more suitable for use in cold regions

Company Introduction:

Shandong Shuangyu Waterproof Material Co., Ltd. was established in 2004. The company is located in Shouguang City, Shandong Province, China, with a registered capital of 5 million yuan and an area of 20,000 square meters. The company has a number of domestic advanced large-scale integrated waterproof material production lines, the main production and sales: SBS modified asphalt waterproof film, self-adhesive modified asphalt waterproof film, self-adhesive waterproof tape, butyl rubber self-adhesive waterproof film, TPO, PVC, HDPE, polypropylene and other polymer waterproof film, polyester non-woven fabric and other waterproof film based fabrics, polyurethane waterproof coating, JS waterproof coating, cement-based penetrant crystal waterproof coating and other leakproof materials.
Products are widely used in various roofing, Bridges, highways, airports, high-speed rail stations, sports venues, tunnel culverts, basements, pipe corridors, garbage disposal sites, kitchen bathrooms and other waterproof, moisture-proof, anti-seepage projects, as well as civil buildings, automobiles, sewage pipes and other anti-seepage, sound insulation, shock absorption, shock absorption materials.

Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 6
 Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 7Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 8Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 9Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 10Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 11


Packaging and transportation:



When acquiring a product, taking into account the packaging and transportation procedures is crucial to guarantee its safe and intact arrival. Here are the steps involved in packaging and transporting waterproofing membranes:

• Packaging: Utilize a roll woven bag along with a lifting strap to safeguard the product throughout the transportation process.

• Protection: For enhanced protection, customers have the option to select wooden crates. This additional measure helps prevent any potential damage during transit.

• Label: The exterior of the packaging will bear clear and easily distinguishable markings. These will include the product name, shipping address, and handling instructions to ensure proper handling.

• Transportation: We possess a professional loading and unloading crew. The products will be transported by a trustworthy and well-established transportation company. The choice of transportation method will be determined by factors such as the quantity, weight, and destination of the products.

• Tracking: Once the product is dispatched, you will be provided with a tracking number. This enables you to monitor the journey of the shipment and anticipate the expected delivery date.

• Delivery: Upon reaching the destination, the product will be carefully unloaded and delivered to the specific location you have designated. It is essential to prepare an appropriate area for the delivery, preferably a flat and even surface, to facilitate a seamless unloading process.


Single Sided Bitumen Waterproofing Membrane , Roof Waterproof Self Adhesive Membrane 12
